The right and left punches are driven by the mechanical linkage of a hydraulic cylinder, realizing the synchronized rigidity feeding of both punches, avoiding useless deforming during the crimping, so as to make more steady junction of window corners.
The interior picker can descend towards below the workbench to facilitate the feeding.
A hydraulic system is used to provide the power, making the operation smooth and reliable.
This machine is of easy operation, reliable properties, advanced technology and is easy to maintain.

Parameters:
Input Power 1.5kw
Power Supply 380V/50HZ
Working Pressure 0.6~0.8MPa
Rated Pressure 15 MPa
Oil Tank Capacity 22L
Applicable Profile Width 90mm
Cylinder Stroke 85mm
Adjustment Range of Main Positioning Block 54mm
Dimensions 1300*1200*1300
Weight 400kg or so
